Led Bulb Machine,Automatic LED bulb making machine

Led Bulb Machine,Automatic LED bulb making machine
Send Inquiry
Product Code : MM-12
Brand Name : MEIAO MUMBAI
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Description

A.

Project:

LED bulb assembly line machines


B.

Dimension

Model type: 12000 L 400"belt) 750" H(mm)


C.

Structure

Single way PVC belt conveyor, galvanized roller transfer, independent frequency control of motor speed.


D.

Description

Stable performance, safety and reliability, simple operation.


E.

Specification



1.

Motor :

Adopt 750W motor, WPS 60 type 1:6 0 of the speed reducer, the Chinese famous brand SONDAO 1 HP's frequency multiplier, frequency conversion sleepless speed regulation, linear speed 2-6m/min can be adjusted.


2.

Machine body

& frame :

Frame made by 40 x 40 square tube, stand by the same 40 x 40 square pipe production and become, below the belt by four points galvanized drum retainer and transfer; Leg match galvanized adjustable foot cup; Head plate with 1.2 mm cold plate bending rolling forming, body 2 meters one pieces.


3.

Conveying belt:

Using the Netherlands imported high quality green light delivery special PVC belt, thickness of 2 mm, width of 400 mm, belt total length is 24000 mm, ring seamless pyro-condensation connection.


4.

Independent

working station :

Independent table, specifications for 800long "600wide 750"mm high(surface treated with antistatics),bilateral arrangement, the 25x 25 rectangular steel tube welding and become, 30L Angle retainer; Bedplate using 15mm quality compression plate, fastening fuselage both sides arrangement. Surface stick green antistatic soft rubber, green T strip edge; Fastening fuselage both sides arrangement.total of 16pcs of working table .


5.

Power

supply arrangement:

1.0 galvanized sheet bending and become, 2000x50x25 galvanized wire slot, is located under the fuselage belt, on both sides installation three, two square socket (every 1 m/workstation install one, bilateral installation).


6.

Lamp lighting:

H type light fixtures are located in the belt on both sides, choose 40 x 20 square tube welding production, connection on the machine body every 2m a frame with cold plate bending a 2000 x 50 25 plastics sprayed slot connection power, makes workers operating space more open, lighting choose LED T8 lamp, bilateral along the line arrangement.


7.

Electric devices

Control:

Full range of electrical control done by a distribution box, with power left and right road control.


8.

Operation card:

Located in the middle frame processing instruction card stand all the way, uses the H - type aluminum rails manufacture, card board with A4 transparent hard plastic.


9.

The upper table

12000 x 400 x 13mm,by 30L angle steel bearing ,made of 13mm high quality plywood ,surface with anti-fire materials, space between the belt is 400mm.
